Main Features:

• IP rated for exterior applications
• Rotating gobo IP65 (optional)
• Linear white CCT from 2,800K to 10,000K, CRI up to 96
• Industry-standard colour gel matching, tungsten emulation on dimming, tint control (+/- green).

LIGHT SOURCE

• Source: 96x3W 6 colour custom LEDs source (red, green, blue, royal blue, mint, pc amber)
• CCT: @full 5.000
• Luminous flux: (5°) 3’805 lm; (10°) 4’790 lm; (14°) 5’047 lm; (19°) 5’380 lm; (26°) 6’681 lm; (36°) 6’814 lm; (50°) 5’773 lm; (70°) 7’430 @full
• Luminous flux: (zoom 15°-30°) (min angle) 5’290 lm; (max angle) 6’664 lm – (zoom 25°-50°) (min angle) 7’042 lm; (max angle) 9’817 @full
• Lux: (5°) 14’638 lx; (10°) 8’663 lx; (14°) 3’812 lx; (19°) 2’530 lx; (26°) 1’759 lx; (36°) 810 lx; (50°) 474 lx; (70°) 306lx @5 m full
• Lux: (zoom 15°-30°) (min angle) 3’502 lx; (max angle) 1’800 lx – (zoom 25°-50°) (min angle) 2’608 lx; (max angle) 974lx @5 m full
• CRI: 93,7 @3.200 K; 97,6 @5.600 K
• R9: 98,6 @3.200 K; 98,2 @5.600 K
• TLCI: 95 @5.600 K
• TM30 Rf: 92 @5.600 K
• TM30 Rg: 100,1 @5.600 K
• Source life expectancy: > 50.000 h

OPTICS

• Lens type: high-quality glass lens optics
• Additional optics: optional 5° / 10° / 14° / 19° / 26° / 36° / 50° / 70° / 90° zoom 15°-30° / zoom 25°-50°
• Focus: manual
• Other: see available accessories

COLOUR SYSTEM

• Colour mixing: RGB, Royal Blue, Mint, PC Amber
• CCT: CCT control, + / – green correction, tungsten emulation
• White presets: 2.800 K ~ 10.000K
• Colour wheel: LEE filter emulation and RGB / HSI / CMY input mode selectable

DYNAMIC EFFECTS

• Rotating gobos: optional, see available accessories
• Gobo size: B, outer: 86 mm – image: 64,5 mm – thickness: 1,1 mm
• Special features: 4 fan modes available and output management and linear crossfade channel from any white to any colour; virtual CTO on colours

BODY

• Body: sturdy die-cast aluminium body
• Body colour: RAL 9004
• Body colour: black

CONTROL

• Protocols: DMX512, RDM
• Stand Alone: selection of static colours, white presets, manual colours and built-in effects with adjustable speed
• DMX channels: UNO / DUO / Basic / Standard / Extended / RAW Direct / RAW 16bit / XYchannel
• RDM: RDM for remote monitoring and settings
• Display: Graphic User Interface
• Firmware upgrade: yes, via USB – DMX interface (UPBOXPRO/UPBOX2) not included (through dedicated software)
• Master/Slave: for synchronised operation of more units linked in a chain

ELECTRONICS

• Dimmer: linear 0 ~ 100% electronic dimmer
• Dimmer curves: 4 selectable dimming modes available
• Strobe / shutter: 1 – 25 Hz, electronic
• Operating temperature: -20° ~ +45°
• LED Control: flicker free operation
• Selectable PWM: 600 ~ 25.000 Hz

ELECTRICAL

• Mains power supply: 100-240V – 50/60Hz
• Max power consumption: 264W
• Standby power: 7,5W
• Output (at 230V): 9 units on a single power line
• Power factor: > 0,95
• Inrush current: ＜30A @115VAC /＜50A @230VAC

PHYSICAL

• IP rating: 65 for temporary outdoor applications, not for fixed installations
• Cooling: low noise fan
• Suspension and fixing: bracket for hanging and positioning
• Signal connection: Seetronic XLR 5p IN/OUT connectors
• Power connection: Seetronic powerCON TRUE IP65 IN/OUT
• Dimensions (WxHxD): 324x540x660mm / 12.76”x21.26”x25.98”
• Weight: 10kg / 22.05lbs

CERTIFICATIONS / APPROVALS

• Certifications / Approvals: CE, UKCA, RCM, cTUVus, FCC

BOX CONTENT

• 1 x ECLCTPLUSIP
• 1 x 1,5 meters power cable (BARE END – SEETRONIC IP65 power connector)
• 1 x Calibration Report
• User Manual
