Main features:

• Linear white CCT from 2,800 K to 10,000 K with CRI up to 97.
• RGB / CMY / HSI 3 ch colours control of the six colours LED array for easy access to any desired colour.
• Industry-standard colour gels matching, tungsten emulation on dimming, tint control (+/- green)

LIGHT SOURCE

• Source: Luxeon-C; 96x3W 6 colour custom LEDs source (red, green, blue, royal blue, mint, pc amber)
• CCT: @full 5,000K
• Luminous flux: (5°) 3,805 lm; (10°) 4,790 lm; (14°) 5,047 lm; (19°) 5,380 lm; (26°) 6,681 lm; (36°) 6,814 lm; (50°) 5,773 lm; (70°) 7,430lm @full
• Luminous flux: (zoom 15°-30°) (min angle) 5,290 lm; (max angle) 6,664 lm – (zoom 25°-50°) (min angle) 7,042 lm; (max angle) 9,817 @full
• Lux: (5°) 14,638 lx; (10°) 8,663 lx; (14°) 3,812 lx; (19°) 2,530 lx; (26°) 1,759 lx; (36°) 810 lx; (50°) 474 lx; (70°) 306lx @5 m full
• Lux: (zoom 15°-30°) (min angle) 3,502 lx; (max angle) 1,800 lx – (zoom 25°-50°) (min angle) 2,608 lx; (max angle) 974lx @5 m full
• CRI: 93,7 @3,200 K; 97,6 @5.600 K
• R9: 98,6 @3,200 K; 98,2 @5.600 K
• TLCI: 95 @5,600 K
• TM30 Rf: 92 @5,600 K
• TM30 Rg: 100,1 @5,600 K
• Source life expectancy: > 50,000 h

OPTICS

• Lens type: high-quality glass lens optics
• Additional optics: optional 5° / 10° / 14° / 19° / 26° / 36° / 50° / 70° / zoom 15°-30° / zoom 25°-50°
• Focus: manual
• Other: see available accessories

COLOUR SYSTEM

• Colour mixing: RGB, Royal Blue, Mint, PC Amber
• CCT: CCT control, + / – green correction, tungsten emulation
• White presets: 2,700 K ~ 10,000K
• Colour wheel: colour gels matching and RGB / HSI / CMY selectable colour mode

DYNAMIC EFFECTS

• Gobo size: B, outer: 86 mm – image: 64.5 mm – thickness: 1.1 mm
• Special features: 4 fan modes available and output management and linear crossfade channel from any white to any colour; virtual CTO on colours

BODY

• Body: sturdy die-cast aluminium body
• Body colour: RAL 9004

CONTROL

• Protocols: DMX512, RDM
• Stand Alone: selection of static colours, white presets, manual colours and built-in effects with adjustable speed
• DMX channels: UNO / DUO / Basic / Standard / Extended / RAW Direct / RAW 16bit / XYchannel
• RDM: RDM for remote monitoring and settings
• Display: Graphic User Interface
• Firmware upgrade: yes, via USB – DMX interface (UPBOX2) not included (through dedicated software)
• Master/Slave: for synchronized operation of more units linked in a chain

ELECTRONICS

• Dimmer: linear 0 ~ 100% electronic dimmer
• Dimmer curves: 4 selectable dimming modes available
• Strobe / shutter: 1 – 25 Hz, electronic
• Operating temperature: -20° ~ +45°
• LED Control: flicker-free operation
• Selectable PWM: 600 ~ 25.000 Hz

ELECTRICAL

• Mains power supply: 100-240V – 50/60Hz
• Max power consumption: 264W
• Output (at 230V): 7 units on a single power line
• Power factor: > 0,95

PHYSICAL

• IP rating: 20
• Cooling: low noise fan
• Suspension and fixing: bracket for hanging and positioning
• Signal connection: Amphenol XLR 5p IN/OUT connectors
• Power connection: Neutrik powerCON TRUE1 IN/OUT connectors
• Dimensions (WxHxD): 264x259x539mm / 10.39”x10.2”x21.22”
• Weight: 7.9kg / 17.42lbs

BOX CONTENT

• 1 x ECLCTPLUS
• 1 x 1.5 meters power cable (SCHUKO plug – NEUTRIK POWERCON TRUE1 IP65)
• 1 x Calibration Report
• User Manual
